MSI B840M GAMING WIFI6E AM5 mATX Motherboard

Product Specifications

Supported CPU: AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors Socket AM5
Chipset: AMD B840
BIOS: Flash BIOS Button
Form Factor: mATX 226mmx243.84mm
Audio: Realtek ALC897 Codec 7.1Channel High Definition Audio
Memory Type: DDR5
Memory Slots: 2 x UDIMM
Maximum Memory: 128GB
Graphics: 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz
LAN Port: Realtek 8125D 2.5G LAN
Wireless Communication: WiFi 6E Solution, Bluetooth 5.3

Product Description

Experience toptier performance and modern features with the MSI B840M GAMING WIFI6E AM5 mATX Motherboard. This powerful motherboard supports the latest AMD Ryzen 9000, 8000, and 7000 Series Desktop Processors, utilizing the advanced AM5 socket and AMD B840 chipset for high compatibility and strong system performance.

The MSI B840M GAMING WIFI6E features dual DDR5 UDIMM slots, supporting up to 128GB of highspeed memory with speeds from DDR5 4800 MT/s up to 8000+ MT/s (OC). Enjoy ultraclear visuals with 1x HDMI 2.1 port and 1x DisplayPort 1.4, both supporting 4K resolution at 60Hz. The integrated Realtek ALC897 codec provides immersive 7.1channel highdefinition audio.

This motherboard offers two PCIe x16 expansion slots, with the primary PCIE1 slot supporting PCIe 4.0 x16, ideal for highend GPUs. For fast storage, it features 2x M.2 PCIe 4.0 x4 slots and 4x SATA 6Gbps ports with support for RAID 0, 1, and 10.

Stay connected with fast and stable wired connections via Realtek 8125D 2.5G LAN and wireless users can enjoy WiFi 6E with speeds up to 2.4Gbps and Bluetooth 5.3. The motherboard also features multiple USB ports, including 2x USB 2.0, 4x USB 5Gbps TypeA, and 1x USB 5Gbps TypeC.

The B840M GAMING WIFI6E features EZ Debug LEDs and EZ Memory Detection LED for easy troubleshooting and includes headers for RGB lighting and addressable RGB effects. With a microATX form factor, it fits perfectly in smaller cases while delivering toptier performance.

Buy the MSI B840M GAMING WIFI6E AM5 mATX Motherboard from Star Tech in Bangladesh and enjoy a 3year warranty. Perfect for casual builders and serious gamers seeking a compact yet powerful AM5 motherboard.

Price: BDT

Available at:

Or Order Online:

Warranty: 3 Years

Brand: MSI

Model: B840M GAMING WIFI6E

Condition: New

Buying Guide:

Check your CPU compatibility
Choose your preferred RAM and storage
Consider your case size and build requirements

Order now and elevate your gaming experience!
